max voltage calculator
Quickly find the maximum allowable voltage for components or systems using RMS/peak conversions, derating, and breakdown limits. Useful for design and safety checks.
voltage derating calculator
AC rms to peak (V peak0=V rms square root 2), derate the components (V safe=V rated times derate). The peak/DC and derated rating are lower in reality as compared to the measured peak/DC and derated rating, respectively.
Formula & Table Summary:
- Vpeak = Vrms × √2
- Vsafe = Vrated × fderate
- Vusable = min(Vpeak/DC, Vsafe)
max voltage calculator
To determine the highest safe value of voltage in components a Max Voltage Calculator uses the conversion of the RMS to its peak value and derating component ratings with respect to factors, and transient margin checks. Use it to prevent over-voltage stress and reliable operation.
breakdown voltage check
| Input Type | Input Value | V_rated (V) | Derate % | Calc | V_usable (V) |
|---|---|---|---|---|---|
| AC RMS | 120 | 200 | 80% | V_peak=169.7 | 160.0 |
| DC | 48 | 60 | 90% | DC=48.0 | 48.0 |
| AC RMS | 230 | 400 | 85% | V_peak=325.3 | 325.3 |
Frequently Asked Questions - max voltage calculator:
What is max voltage?
The highest voltage a component or system can safely withstand under expected conditions.
How do I convert RMS to peak?
Use V_peak = V_rms × √2.
What is voltage derating?
Applying a safety factor (e.g., 80%) to a component’s rated voltage to extend life and reliability.
Should I use peak or RMS to compare with component rating?
Compare component rating to peak (instantaneous) stress; convert AC RMS to peak first.
What derating factor should I use?
Depends on application; typical values range 0.6–0.95 — follow component datasheet recommendations.
How do I handle transients and spikes?
Include transient margin in your comparison or use surge protection/clamping devices.
Is V_rated always safe?
V_rated is the maximum specified — operating at or below a derated value is safer and increases lifetime.
What about RMS vs DC ratings?
DC ratings are steady-state; AC RMS must be converted to peak to check instantaneous stress.
How to check capacitor max voltage?
Compare capacitor V_rated × derating factor to expected peak voltage; capacitors often need larger derating.
Can I increase V_max by cooling?
Lower temperatures can improve dielectric strength but always follow datasheet limits and derating guidance.
