DC Motor Total Power Loss Calculator
Calculate total power loss in a DC motor, including copper, iron, mechanical, and stray losses for efficiency and performance analysis.

dc motor loss estimation tool
A DC motor total power loss calculator calculates, Copper, Iron, Mechanical & stray-load Loss to ensure accurate efficiency and performance.
Formula & Table Summary:
- Copper Loss: Pc = Ia²Ra + If²Rf
- Iron Loss: Pi = Wh + We
- Mechanical Loss: Pm = Friction + Windage
- Total Loss: Ptotal = Pc + Pi + Pm + Pstray
- Efficiency: η = Pout / (Pout + Ptotal) × 100%
hysteresis and eddy loss dc motor
DC Motor Total Power Loss Calculator estimates all the significant losses within the DC motor that make the motor less efficient. The losses in power are encountered because of resistive heating, the iron core, and friction, among other stray loads. Four main losses in a DC motor are: Copper Loss (I2R Loss): As a consequence of current flowing through armature and field windings. Core (Iron) Loss: Contains hysteresis and eddy current losses, which occur in the magnetic core. Mechanical Loss: Loss because of bearing friction and windage. Stray Load Loss: Small losses on the load of a more miscellaneous nature. With such losses added up, it is possible to estimate the total power loss and motor efficiency. This is critical in designing, testing, and making the appropriate motor choice in the industry.
dc motor total power loss calculator
| Ia (A) | Ra (Ω) | Pc (W) | Pi (W) | Pm (W) | Pstray (W) | Ptotal (W) |
|---|---|---|---|---|---|---|
| 50 | 0.2 | 500 | 150 | 100 | 50 | 800 |
| 75 | 0.25 | 1406 | 180 | 120 | 60 | 1766 |
| 100 | 0.3 | 3000 | 200 | 150 | 80 | 3430 |
| 120 | 0.35 | 5040 | 250 | 200 | 100 | 5590 |
Frequently Asked Questions - DC Motor Total Power Loss Calculator:
What are the main losses in a DC motor?
Copper, iron, mechanical, and stray load losses.
How do you calculate copper loss in a DC motor?
By I²R of armature and field windings.
What causes iron loss in DC motors?
It is caused by hysteresis and eddy currents in the core.
What are mechanical losses in DC motors?
Losses due to bearing friction and windage.
What are stray load losses?
Small miscellaneous losses that occur under load.
How is total power loss in a DC motor calculated?
By adding copper, iron, mechanical, and stray losses.
Does total power loss affect efficiency?
Yes, higher total losses reduce motor efficiency.
Is core loss present at no load?
Yes, iron loss is present whenever flux exists.
How do you improve motor efficiency?
By reducing resistance, using high-grade core steel, and better lubrication.
Can losses in DC motors be eliminated?
They cannot be eliminated but can be minimized through design and maintenance.
