Differential switch wiring diagram
Learn how to control two lights from three places using ladder wiring with two-way and four-way switches for safe and efficient operation.

two lights with four-way switch
A two-way switch may be used at both ends of each light, and one four-way switch in the middle to control the lights in three locations. The line reaches the first switch, then the travelers pass through the four-way switch and the second switch then joined to the lamp, and the Neutral is directly connected to the lights.
hall two light three switch control
A ladder wiring diagram shows how to connect switches and lights in a step-by-step manner like rungs of a ladder. To control two lights from three places, we need two two-way switches and one four-way switch per circuit.
For each light:
- The Line (Phase) is connected to the COM terminal of the first two-way switch.
- Two traveler wires link the first two-way switch to the four-way switch.
- Another two traveler wires connect the four-way switch to the second two-way switch.
- The COM of the second two-way switch goes to the light (Load).
- The Neutral wire connects directly to the light.
By repeating the same circuit for both lights (or using double-pole switches), you can control Light1 and Light2 from three different switch locations. This setup is commonly used in staircases, corridors, and large rooms.
Work / Installation (Inputs → Outputs)
- Input: Line → Switch1 (COM)
- Travelers: Switch1 (L1/L2) → Four-way Switch → Switch2 (L1/L2)
- Output: Switch2 (COM) → Lamp → Neutral
Repeat this for both lamps (Light1 & Light2).
Testing and Final Adjustments
Wire and then turn ON the MCB and test the two lights. Toggle any of the three switches (Switch1, Four-way, or Switch2) - the light to which one is connected should go ON/OFF. Test both lights separately. When a light has only one working position, the traveler connections may have been switched. Always be sure that Neutral is straight to the lights, and that only the Line is turned off. Colour coded to facilitate troubleshooting: Line red/brown, Neutral black/blue, and Earth green/yellow. Clamp screw ends and wrap up open copper wires with tape. Mark switches to prevent confusion when both lights are operated adjacent to each other.
Frequently Asked Questions - Differential switch wiring diagram:
What is ladder wiring?
Ladder wiring is a method of representing electrical circuits like a ladder with switches and loads.
How many switches are needed for two lights controlled from three places?
Each light needs two two-way switches and one four-way switch.
Where does the Neutral wire go?
Neutral connects directly to the lamp terminals.
What is the function of the four-way switch?
A four-way switch allows traveler wires to be extended so a load can be controlled from three or more places.
Can I use double-pole switches for both lights?
Yes, DP two-way and DP four-way switches can control two lights in one wiring set.
Where is ladder wiring used?
It is used in staircases, long corridors, halls, and multi-entry rooms.
Can LED bulbs be used in this wiring?
Yes, LED bulbs work the same way as incandescent bulbs in this wiring.
What if a light flickers?
Check loose traveler connections or replace a faulty switch.
Can I expand control to four or more places?
Yes, add additional four-way switches between the traveler wires.
Is earthing required?
Yes, always connect earth to the metal body and switchboard for safety.
