12V Battery Charger Circuit Using TIP120 Transistor

🇺🇸
English
Default
🇪🇸
Español
Spanish
🇫🇷
Français
French
🇩🇪
Deutsch
German
TIP120 Transistor

TIP120 Transistor

NPN Darlington power transistor with high current gain

50K Fixed Resistor

50K Variable Resistor

Adjustable resistor with 50,000 ohm resistance

1K Fixed Resistor 1W

1K Fixed Resistor 1W

A 1,000-ohm resistor rated for 1 watts

DC Voltage Meter

DC Voltage Meter

An instrument used to measure the direct current (DC) voltage across two points in a circuit, typically displayed in volts (V).

*Please note: These are affiliate links. I may make a commission if you buy the components through these links. I would appreciate your support in this way!

Battery Charger

Build a simple 12V battery charger using a TIP120 transistor. Safely charges lead-acid batteries with automatic current regulation for protection.

TIP120 battery charger circuit

Battery Charger with TIP120 is a safe and simple to assemble circuit that has been developed to charge 12V lead-acid or lithium batteries. The TIP120 Darlington transistor is used as a series pass element to regulate the current flowing to the battery. The charging current can be regulated by moving the potentiometer in the circuit, so that charging will be safe and the battery will not be charged excessively. This charger is based on a basic voltage reference, a diode rectifier, and a filtering capacitor to convert AC into DC. The TIP120 has control of the output current and voltage, enabling it to be charged effectively. The circuit can be used in small batteries in cars, UPS systems, or for storing solar energy. The low number of components it uses makes it a good project for DIY electronics lovers and offers safety against cases of overcurrent.

automatic battery charging circuit

A TIP120-based battery charger is an automatic, regulated charger that charges batteries with 12V of safe and efficient battery charging.

Work / Installation (Inputs → Outputs)

  • AC Adapter Input → Rectifier and filter convert AC to DC.
  • TIP120 Transistor Stage → Controls current flow to the battery.
  • Voltage & Current Adjustment → Potentiometer sets safe charging level.
  • Battery Output → Receives regulated DC until fully charged.

Testing & Final Adjustments

Connect a 12V power supply and battery after assembling. Watch the output voltage and use the potentiometer to set it to the right charging current. Check the voltage on the battery with a multimeter. Check the TIP120 to see that it does not overheat, and add a heat sink when necessary. Test the charger by emptying and refilling the battery to make sure that it works each time. Make sure all the AC/DC connections are insulated. Lastly, ensure that the charger turns off/reduces the current when the battery is full. Adequate changes will save the battery and increase its lifespan.
